Одноконтактна безцокольна 7440 (Т20) (W21W)-10HP+6LED червона.

Одноконтактна безцольна 7440-10HP+6LED червона.

Description: Design a H-7440-10HP+6LED constitute ,High and bright degree Light with good even ,used in various as stop light;and with each kind of illuminatio

Character:

12V~24V(Totally use )--- The product uses the high radiation the copper and the aluminum makesthe good radiation;Has the very good luminous efficiency and the stability;Has quakeproof and is moisture-proof;The diameter of the exterior 20 millimeters applicably various type of car ;May use in the direction lamp and each kind of illumination, The inner part has already born to press settling of 35 Vs' electric current IC and significant exaltation to give out light an efficiency.

Specifications:

(A) Electronics and Optical Characteristics: Ta=25˚C

PART NO: 7440-10HP+6LED

Color
Emitting

Color
Forward

Voltage(DC)

Unit: V
Totality

Luminous

Intensity

Unit: LM

Error margin:±5%
Dominant

Wavelength

Unit:nm
Color

Temperature

Unit:K
Single LEDIntensit

Unit:mcd (0.5m)
Viewing

Angle

Unit:deg


W
Super

White
14.2
58.97
X:0.280 Y:0.298
7000-9000
6233
158.2


B
Ultra

Blue
14.2
14.58
466～460
> =100000
1757
153.8


G
Ultra

Green
14.2
68.76
534～525
7243
6622
155.5


R
Super

Red
14.2
43.41
623～630
1001
3683
154.3


Y
Super

Yellow
14.2
30.11
589～590
1445
2070
154.9

Test Condition Power:2.21W Current:170±10%mA
